In the realm of HVAC technology, air handling systems stand as crucial game-changers, balancing comfort with efficiency. Dive into this exploration of air handling units, particularly spotlighting Saiver’s innovations available through IACS. Looking for top-notch energy efficiency and cost savings? You’re in the right place.
What are air handling systems?
Before we get into the efficiency and cost savings that can be achieved by products sold by IACS, let’s briefly explore exactly what air handling systems are. Air handling systems, often referred to as air handling units (AHUs), are integral components of HVAC (heating, ventilation, and air conditioning) systems.
Their primary function is to treat the air, ensuring it is clean, adequately humidified or dehumidified, and at the desired temperature, before circulating it throughout a building or facility. These systems play a pivotal role in maintaining indoor air quality and ensuring comfortable conditions for occupants.
How air handling systems work
- Air intake: Air is drawn into the system, which can be a mix of fresh outdoor air and recirculated indoor air.
- Filtration: As the air flows through, it’s first filtered to remove contaminants.
- Temperature adjustment: Depending on the need (cooling or heating), the air is passed over the respective coil to bring it to the desired temperature.
- Humidity control: If required, the system adjusts the humidity levels using humidifiers or dehumidifiers.
- Distribution: The treated air is then circulated throughout the building using ductwork and fans.
- Exhaust: A portion of indoor air is often exhausted outside to regulate air quality and pressure.
By performing these functions, air handling systems ensure a consistent and comfortable indoor environment, free from excessive pollutants, and at desired temperature and humidity levels.
Saiver air handling units
Air handling systems play an indispensable role in maintaining optimal indoor air quality, temperature, and humidity. While generic systems abound, Saiver has carved a niche in providing tailor-made solutions that transcend traditional boundaries. Our flagship product is the A1 Series—it’s designed particularly with the evolving needs of data collection and management centres in mind.
Distinctive features of the A1 Series Air Handling Unit:
A blend of dedicated research, adaptability, and innovation tailored for diverse environments. Dive into its distinguishing features;
Seamless adaptability for various sectors
Crafted through continuous research and development since Saiver’s inception, the A1 Series is a testament to versatility and innovation. This product effortlessly aligns with diverse customer needs and finds applications across multiple sectors. Whether it’s the rigorous demands of industrial environments or the precise requirements of commercial spaces, the A1 Series is engineered to deliver.
Reliability and cost-effectiveness
Saiver’s commitment to performance and value shines brightly with the A1 unit. Not only does it promise high energy efficiency, but its design also ensures longevity and reduced maintenance costs. This combination of operational excellence and cost-effective functioning makes the A1 Series an attractive proposition.
Modular design ensuring flexibility
Understanding that every space has its unique challenges and requirements, the A1 Series comes with a modular design. This ensures customisation to cater to specific needs, making installations and transport more efficient, subsequently curbing both time and expenses.
Performance and compliance specifications
- Capacity: Varies between 500 m³/h and 300,000 m³/h.
- Dimensions: Fully bespoke to match individual project requisites.
- Performance metrics: With a mechanical resistance of class D1, air loss rate class L1, heat transmission class T1, and a thermal bridge factor class TB2, the A1 Series stands out in operational excellence.
- Regulatory conformance: Abiding by European standards, it comes with the prestigious EUROVENT certification and aligns with EU Regulation No. 1253/2014, underlining its quality and trustworthiness.
Versatility across applications and features
Saiver’s A1 unit is meticulously designed to satisfy a broad spectrum of design, technical, and dimensional requisites. Key features include:
- IAQ control: Ensuring the highest quality of air.
- Integrated heat pump: Provides a comprehensive temperature regulation solution.
- Proprietary software control: Allows for precise and efficient system management.
- Antibacterial and antiviral actions: Ensuring the utmost in health and safety standards.
- Noise control adjustments: A crucial feature for maintaining a conducive environment in various settings.
- Compliance with marine and ATEX regulations: Making it apt for specialised environments.
- Easy maintenance & internal cleaning: A crucial aspect to ensure longevity and efficiency.
- The frame: The modular framework of the A1 series utilises a corrosion-resistant, extruded marine aluminium alloy. It features a patented twin box section with true thermal break construction, providing both strength and thermal insulation. The entire module is mounted on a heavy sectional aluminium alloy or galvanized steel channel, ensuring a robust and durable structure.
- Infill panels: The A1 series comes with standard 30 mm or 60 mm thick infill panels. These panels are of double-skinned construction and are made from pressure-injected polyurethane foam insulation, contributing to better thermal performance and energy efficiency.
- Accessibility: Maintenance is made easy in the A1 series with accessible design features. Filters, coils, air washers, and fan sections requiring regular maintenance and inspection are fitted with either hinged or fully removable access panels, ensuring quick and hassle-free access for routine servicing.
- Filters: The A1 series offers a range of filter options, spanning from coarse dust filters to high-grade filtration systems like HEPA. This ensures optimal air purity for various applications, meeting stringent air quality requirements.
- Accessories: These include a lamp switch for convenient illumination control within the unit, a bulkhead lamp that provides adequate lighting for inspections and maintenance activities, and an inspection window that allows for easy visual assessment of the unit’s interior without the need to open it up.
- Heat recovery systems: These include battery-operated, plate with cross flow, and rotating systems, ensuring efficient temperature regulation.
- Humidifiers: A diverse range from isothermal steam humidifiers to ultrasonic ones, catering to varied humidity control needs.
- Fans: Incorporating advanced fan systems such as EC fans with brushless technology.
- Dehumidifier: Leveraging a drying wheel, it effectively eliminates humidity, which is crucial in industrial and pharmaceutical sectors.
How do Saiver’s air handling systems lead to energy efficiency and cost savings?
Saiver’s air handling systems such as the A1 Series, employ a range of features and design principles that significantly contribute to energy efficiency and subsequent cost savings. Let’s delve into the details:
Advanced cooling systems
- Evaporative cooling: Saiver employs both direct and indirect evaporative cooling methods. Evaporative cooling is highly energy efficient as it utilises the natural process of water evaporation to cool the air, consuming significantly less energy compared to traditional air conditioning systems.
- Multiple options: By offering systems with direct expansion, chilled water, and liquid cooling options, Saiver ensures that the most efficient method is used for the given application and environment.
Customised design and modularity
Every facility or building has unique needs, and a standardised approach isn’t always the most efficient. By allowing for complete personalisation in dimensions and modular design, Saiver ensures that every unit is optimised for its specific application. An optimised system runs more efficiently, leading to energy and cost savings.
With mechanical resistance, air loss rate, heat transmission, and thermal bridge factor classifications that are top-tier, Saiver’s units ensure minimal energy wastage. Better mechanical resistance means the units can handle more without working harder. Lower air loss rates mean that less cooled or heated air escapes the system, ensuring optimal efficiency.
Conformity and certification
The A1 series, for instance, conforms to European regulations and has a EUROVENT certification. Compliance with such standards and certifications ensures the units operate at peak efficiency levels and adhere to best practices in the industry.
Features like integrated heat pumps in some units can lead to both energy and cost savings. Heat pumps are known for their efficiency, as they transfer heat instead of generating it.
Proprietary control software allows for real-time monitoring and optimisation of the system’s operation, ensuring it runs efficiently at all times.
Durability and low maintenance
Designed for a long lifecycle and characterised by low maintenance costs, Saiver’s units reduce the need for frequent repairs or replacements. A system that requires less maintenance not only saves direct maintenance costs but also ensures uninterrupted efficient operation, preventing energy wastage and unexpected downtimes.
Specific material choices
Saiver’s emphasis on choosing specific materials for different applications, like compliance with marine standards or ATEX regulations, means that each system is ideally suited to its environment. When a system is made of materials best suited to its operating conditions, it runs more efficiently and lasts longer.
In essence, Saiver’s approach to air handling system design, combined with their advanced technology and commitment to quality, ensures that their units lead to notable energy efficiency. Over time, this translates into significant cost savings for the end-user, both in terms of energy bills and reduced maintenance costs.
Saiver’s air handling systems, distributed by IACS, epitomise the fusion of advanced technology and sustainability. For those seeking reduced energy bills and a greener footprint, Saiver offers the perfect solution. Don’t wait. Invest with IACS today (we have locations in Perth, Brisbane, Melbourne, and Sydney) and step into the future of HVAC efficiency.
